Crane
Used ZOOMLION QY55V
Original ConditionLX-QY55V
$40,000indicative asking price · negotiable
- Year
- Not recorded
- Hours
- Not recorded
- Condition grade
- Not graded yet
- Location
- Sourced to order
- Availability
- Sourced to order after confirmation
- Warranty
- Ask us
Year, hours and grade appear only where we have verified them. See what every machine is checked against · Delivery standards
Request a quote
Get a personalized quote within 1 business day.
Specifications
| Device model | QY55V |
|---|---|
| Whole vehicle whole preparation mass (kg) | 41870 |
| Driving self weight (total mass) (kg) | 42000 |
| Front axle load (kg) | 16000 |
| Front and rear axle load (kg) | 26000 |
| Rated total lifting capacity (kg) | 55000 |
| Outrigger span (longitudinal x transverse) (m) | 7.1X5.92 |
| Basic arm maximum lifting torque (kN·m) | 2009 |
| Basic arm maximum lifting height (m) | 12.6 |
| Maximum lifting moment of the longest main boom (kN·m) | 1050 |
| MAXIMUM LIFTING HEIGHT OF THEMain Arm (m) | 43.6 |
| Secondary arm maximum lift height (m) | 59.5 |
| Revolution radius of the tailstock (mm) | 3900 |
| Single rope maximum speed (main winch) (m/min) | 120 |
| Single Rope Maximum Speed ( auxiliary winch ) (m/min) | 120 |
| Lifting arm luffing/desluffing time (s) | 50 |
| Lifting boom fully extended/fully retracted time (s) | 95 |
| Revolution speed (r/min) | 0-2.2 |
| Maximum speed (km/h) | 76 |
| Maximum climbing gradient (%) | 40 |
| Minimum turning radius (m) | ≤24 |
| Minimum ground clearance (mm) | 260 |
| Fuel consumption at 100 km (L) | ≤43 |
| Dimensions (length x width x height) (mm) | 13700x2800x3650 |
| Outrigger longitudinal distance (m) | 5.92 |
| Boiler support transverse distance (m) | Full extension 7.10, half extension 4.80 |
| Boom length (m) | 11.4 to 43.0 |
| Boom elevation (°) | -2 to 80 |
| Deputy Arm Length (m) | 9.5, 16 |
Description
High-stability crane with 5.5-ton counterweight, wide outrigger span, powerful boom reach, ergonomic cab, advanced control systems, robust chassis, and efficient hydraulics for safe, versatile, and energy-saving lifting operations.
